Representing an evolution in the highest performance LED lighting solutions, the Elite and Elite+ range comprises products with enhanced performance, light distribution, and functionality. Superior white light high beam function for awe-inspiring night-time visibility at a slightly softer, more relaxing color temperature with that light angled slightly down and to the sides of the road or track making this function ideal in snow, fog, or dust conditions.
SPECIFICATIONS
LINEAR-6 YELLOW
LINEAR-6 ELITE
LINEAR-6 ELITE+ (LOW OUTPUT / BOOST)
Voltage Range (DC)
10-32V
10-32V
10-32V
LED Life
50,000 hrs
50,000 hrs
50,000 hrs
Weight
1.1 lbs
1.1 lbs
1.1 lbs
HIGH BEAM FUNCTION
Total Luminous Flux
4,320 Lm
4050 Lm
5100 / 2500 Lm
Total Driver 'FOV' Flux †
2,839 Lm
2884 Lm
3645 / 1822 Lm
Colour Temperature
PC Yellow
5000K
5000K
Power Consumption
42 Watts
42 Watts
48 W / 24 W
Current Draw (14.4V)
2.9 Amps
2.9 Amps
3.6 A / 1.8 A
CERTIFICATION
IP Rating #
IP68
IP68
IP68
EMC Certification
ECE R10
ECE R10
ECE R10
Salt Spray Test
ISO 9227
ISO 9227
ISO 9227
Dump Load Protection
ISO 7637-2
ISO 7637-2
ISO 7637-2
PHOTOMETRIC DATA
Horizontal / Vertical Beam Angle
84° / 18°
64° / 15°
84° / 18°
0.25 lx Line
536m
563 m
600m / 424m
0.5 lx Line
379m
398 m
424m /300m
1 lx Line
268m
282 m
300m / 212m
3 lx Line
155m
163 m
173m / 122m
† - Driver FOV flux is a measure of effective lumens taking consideration of the amount of light in a driver's 'field-of-view' defined as an area +/- 45° left/right, and +/- 10° up/down.
# - All Lazer products are designed to meet the requirements of IP68 testing. Every lamp produced at our UK facility is fully submerged under water prior to sending out.
